Saturday, July 10, 2021

La Havana ancient map


Sail south from the Dry Tortugas across the Straits of Florida and in no time the 506-year-old city of Havana, Cuba will appear on the horizon; colorfully presented in this 1762 French map by J. N. Bellin, when its population exceeded New York City's.
Harvard Library

La Havana 2021 GeoCuba in the GeoGarage platform


Friday, July 9, 2021

Squid communicate with a secret, skin-powered alphabet



The oval squid.
Science Source

From Wired by Anna Vlasits

Once they get over being creeped out, maybe scientists will figure out what cephalopods are saying.
Squid use a remarkable array of skin patterns to communicate.
How? It's all a matter of getting inside their heads.

Squid and their cephalopod brethren have been the inspiration for many a science fiction creature.
Their slippery appendages, huge proportions, and inking abilities can be downright shudder-inducing. (See: Arrival.)
But you should probably be more concerned by the cephalopod’s huge brain---which not only helps it solve tricky puzzles, but also lets it converse in its own sign language.

Right now, you're probably imagining twisted tentacles spelling out creepy cephalopod communiqués.
But it's not that: Certain kinds of squid send messages by manipulating the color of their skin. "Their body patterning is fantastic, fabulous,” says Chuan-Chin Chiao, a neuroscientist at National Tsing Hua University in Taiwan.
They can display bands, or stripes, or turn completely dark or light. And Chiao is trying to crack their code.



Chiao got his inspiration from physiologist B. B. Boycott, who in the 1960s showed that the cuttlefish brain was the control center for changing skin color.
Boycott copied his technique from neurosurgeon Wilder Penfield, who treated epilepsy patients by burning out the misbehaving bits of their brains.
While their grey matter was exposed for surgery, Penfield* *also applied a gentle current through the electrodes in his patients’ brains. You know, just to see what would happen.

A zap in one spot above the ears caused a tingle in the left hand. In another spot, tingles in the leg. And so Penfield discovered that the sensory cortex is a homunculus, with specific brain areas mapping onto different parts of your body.
Over time, scientists tried the electrical stimulation technique on all kinds of animals---including Boycott's cuttlefish.

Chiao tried out the same thing in a related cephalopod, the oval squid---but he took it to the next level.
In a paper published in the Journal of Neuroscience in January, he describes putting electrodes in a bunch of different parts of the optic lobe, stimulating them, and recording the resulting body patterns.
"Those optic lobes are the mystery of the cephalopod nervous system," says Roger Hanlon, a marine biologist at the Marine Biological Laboratory at Woods Hole.

When Chiao started out, he thought the optic lobe would be organized like the human cortex, with the pigment on different body parts correlating with different locations in the brain: a squidunculus.
Not so.
“When we finished the experiment," says Chiao, "we looked at the data and it was really puzzling." He'd poke in the left part of the optic lobe, and the squid’s mantle would turn black.
Then, he'd poke in the right region---and the same thing would happen.
It seemed like the squid's body parts were represented in more than one spot in the optic lobe.

After Chiao and his student Tsung-Han Liu had stared at the data for a long time, a hypothesis began to emerge. The squid’s pigment cells are surrounded by muscles that stretch the pigment cells out or let them curl up. Instead of controlling body parts, the optic lobe controls those muscles. When Chiao stimulated in one spot, the squid’s mantle turned dark. Another spot, the mantle got thick, horizontal stripes. Another, the mantle got one thin vertical stripe.

Each part of the body has its own patterns, so a squid can simultaneously have polka dot fins, dark tentacles, and a stripy mantle.
It’s like the squid has an alphabet of patterns---14 by Chiao's count---which repeat in a mosaic within the optic lobe. It's like if your keyboard had hundreds of keys, but still only 26 letters.
That redundancy, Chiao hypothesizes, is how the squid can execute a new combination as quickly as once a second.

Eventually, scientists will make an even more detailed map of what each individual neuron is doing in this brain area.
Hanlon's excited for that day, especially because the squid brain appears to be so different from vertebrate brains.
"Their body plan is so bizarre compared to ours that it’s hard to compare their brain structure and function to something that we know," he says.

And for now, Chiao wants to know what different combinations of pigment patterns might mean to an onlooking squid.
He's recording the patterns that squid take on when they're together and correlating them to their behavior, like mating and male-on-male aggression.
Perhaps soon he’ll find out whether squid are having complex discussions about squid politics, or (more likely) just figuring out who has the bigger mantle.


Strange and unusual life inhabits the plankton rich seas of the underwater kelp forests.
Watch this short video from BBC natural history series The Blue Planet to see the mating habits of amazing colour changing squid and the weird movements of the aptly named hand fish


Thursday, July 8, 2021

Can massive cargo ships use wind to go green


The MV Afros off New Orleans.
Credit...Spencer Lowell for The New York Times

From NYTimes by Aurora Almendral

“Can we harness the wind? Yes.
Can we do it at a cost that is tolerable to the market? That’s the question we’re answering now.”
Cargo ships belch as much carbon into the air each year as the entire continent of South America.
Can wind propulsion technology with highly advanced rotor sails solve the shipping industry's carbon problem?

Cargo vessels belch almost as much carbon into the air each year as the entire continent of South America.
Modern sails could have a surprising impact.

In 2011, Gavin Allwright was living in a village outside Fukushima, Japan, with his wife and three children, when a powerful tsunami destroyed the coastline, splintering homes into debris, crashing a 150-foot fishing boat into the roof of his wife’s parents’ house and setting off a power-plant accident that became the worst nuclear disaster since Chernobyl.

Allwright had a background in sustainable development, especially as it relates to shipping.
In his travels in East Africa and Bangladesh, he had watched traditional sails and masts replaced by outboard motors.
The move locked people into a cycle of working to buy fuel, damaging their lives and the environment.
In Japan, Allwright had been living a quiet life, running a sustainable farm and dabbling in consulting.
Now, it seemed, environmental disaster had followed him there.

To escape the aftermath, the family moved to Allwright’s hometown on the outskirts of London.
But Allwright couldn’t stop thinking about the Fukushima disaster.
To him, it was a dramatic display of technology going wrong, further proof that the world we built is unsustainable.

He thought about shipping.
It produces 2.9 percent of global carbon-dioxide emissions, almost as much as the entire continent of South America.
With every country benefiting from global trade, it could be argued that shipping is everybody’s responsibility, but it is treated as if it is nobody’s.
In the vast but liminal space of the ocean, cargo vessels — some of the largest machines on the planet — have generally operated in obscurity.
The industry’s greenhouse-gas emissions have only grown as world trade has expanded, about 10 percent in the last six years.
Shipowners, charterers and regulators have done little about the situation.

Allwright had previously spent 10 years working with a group that tried to build small cargo ships that would run on wind power to eliminate their carbon footprint.
It underscored for him that sails aren’t a relic of the past.
At the most fundamental level, the way modern sails work is similar to the way sails did a thousand years ago: As wind moves against their curves, it creates a high-pressure system on one side and a low-pressure system on the other, resulting in a forward thrust that pushes the ship along.
But the design, materials and size of modern sails, along with the ships’ movements, allow them to harness significantly more power from the wind than the cloth sails of the past — enough so that they can move a huge cargo vessel.
In conjunction with fuel, modern sails can power ships with something close to the speed and predictability to which the global economy is accustomed.

The group Allwright worked with never managed to get the ships built.
Looking back on it, he believed it was a commercial failure, not a technical one.
In 2014, he started the International Windship Association, a trade association, bringing together disparate groups of inventors, researchers and others who wanted to get modern wind propulsion on cargo vessels — not to replace fuel entirely but to require considerably less of it.

Climate change, Allwright told anyone who would listen, would create intolerable pressures.
He would point them to books and reports by scientific organizations like the Intergovernmental Panel on Climate Change that outlined what would happen if the world stayed on its current trajectory, sending average temperatures up 3 degrees or more: vicious wars over resources, mass refugee migrations, major cities engulfed by rising seas. And because this was a crowd of businesspeople, he would mention, too, that all of that would be catastrophic for the economy.

This preaching of sustainability was heard, at first, as an act of aggression.
Shipping executives would walk out of meetings and slam the doors as they left.
When he brought up numerical targets for carbon-dioxide emissions from shipping, someone shouted that it would never happen.
“It’s a fantasy!” another yelled.
Then, in the last couple of years, something shifted.
The industry has been facing more pressure to emit less carbon, but one of the most talked-about methods of reducing shipping’s carbon footprint — using alternative fuels such as hydrogen — is costly and difficult to pull off.
Wind propulsion, on the other hand, is already available.


WISAMO is an innovation initiative from Michelin Group and develops an inflated, foldable and automated wing using wind propulsion as an hybrid solution to reduce fuel consumption and then greenhouse emissions like CO².
The wing can be adapted to any kind of vessels, new ones or the ones already operating: Ro-Ro, bulk cargos, oil and gaz tankers, containers as well as sailing and yacht boats.
Thanks to WISAMO, Michelin aims to contribute to maritime transport decarbonization.

The fact that shipping is contributing significantly to climate change has become so well understood among shipowners that Allwright has been able to delete the two or three slides in his presentation that outlined the industry’s carbon emissions and its impact on the environment.
An exception is presentations in the United States, where there are inevitably audience members who don’t believe in man-made climate change.
For them, he keeps the environmental slides in, while emphasizing the economic argument: Fuel can be expensive, especially if, in the future, the price of oil spikes, taxes on carbon emissions drive up its cost or the industry is forced to shift to green fuels.
Wind is free.
If wind-propulsion technologies could be offered cheaply enough, the reduction on fuel use from wind-assisted ships may well make them more cost-effective than conventional combustion-engine ones.

Allwright’s trade association has grown, with about 40 companies now developing wind-propulsion technologies.
They include a Finnish company that is installing sails on existing vessels, as well as businesses in Britain, France, China and Japan.
Fifteen large wind-assisted ships are already on the water.
Another five are expected to go into sea trials and enter the market soon, and more than 20 are in late-stage prototypes.

Yet unanswered is whether the sails can be made cheaply enough — and can save enough fuel — to make it worthwhile to install them.
“Can we harness the wind?” Allwright asked.
“Yes.
Can we do it at a cost that is tolerable to the market? That’s the question we’re answering now.”

One afternoon in late April, I boarded the MV Afros, one of the wind-propulsion ships already in use, which is working as a cargo vessel and providing an early proof of concept.
A conventional combustion-engine ship has a life span of 20 to 30 years, and this initial stage of modern wind propulsion largely involves retrofitting sails onto existing ships, using wind to cut down on some fuel use until the ships are scrapped.
The MV Afros was fitted with sails from the start, using Flettner rotors, a technology that has existed since the 1920s.
The rotors — spinning cylinders powered by the ship’s diesel-fueled generator — are mounted on the deck of the ship.
Though they bear no resemblance to the sails of old, they function like them: Wind splits into high- and low-pressure systems when it hits the rotors, creating thrust that pulls the ships forward.

The MV Afros, named after a Greek word for the white foam on the tip of a wave, had just pulled into one of the berths of St.
Bernard Port in New Orleans — its first discharge stop after a 34-day voyage from Gwangyang, South Korea — to unload a cargo of cold-rolled steel coils.
I stood on the deck and peered down into one of the holds, where a pair of dockworkers in high-visibility vests stood deep in the bottom, scarcely taller than the coils of steel and dwarfed by the cavernous scale of a ship built to carry more than 63,000 metric tons of goods.

The rotors were on the starboard side: four columns painted in white, each 52 feet tall and seven feet in diameter — wide enough for a seafarer to crawl in and make repairs.
I clambered around the deck, past heaving cranes and over thick, greasy coils of mooring rope, and ran into three deckhands in hard hats and orange jumpsuits.
They boarded the Afros just four days earlier, during a brief stop at the Panama Canal.

I asked them what they thought of the sails.
They were, at first, confused.
Then I gestured at the rotors.
They told me it was the first time they’d seen such a sight or heard the deep whir that comes from the rotors at full spin.
Their first thought was excitement.
“High-tech,” one of them said.
The next thought was of obligation.
“Of course, it adds to our work,” he noted — a new set of maintenance hassles to deal with.
“But when it comes to the environment, it helps.”

The Afros was the brainchild of Costas Apodiakos, a member of the third generation of a Greek shipping family.
He first realized something had to be done about the industry’s pollution in the late 1970s while on an apprenticeship on a vessel docked in Alexandria, Egypt, where a beautiful sunset struck a discordant note with his surroundings: acrid water slicked with oil and chemicals; trash, tossed over the side of the ship, drifting with the current.

He became interested in using sails on his cargo ships, but it took another 20 years before wind-propulsion materials became light and cheap enough and the technology advanced enough — and nearly another 20 years before Apodiakos could develop, test and install rotors on the Afros, which is managed by a company started by his family.
That was in 2018.
In the three and half years since, the Afros has been bouncing to ports around the world — 59 of them so far — carting sand, fertilizers, iron ore, manganese, soybean meal, steel slabs and sulfur.

Apodiakos’s wind-propulsion company, Anemoi Marine Technologies, is now beginning to sell its rotor sails to others, for $350,000 to $1.1 million apiece, depending on the size, with another $500,000 in installation costs.
An Anemoi representative says the company is planning to install three rotors on a customer’s ship in 2022.

On the bridge overlooking the deck and sails, Antonios Mandas, the second officer, showed me the controls for the rotors.
I was surprised at how simple they were.
There are four yellow remotes, one for each rotor.
Each remote has eight big black rubber buttons used to control the trolleys that slide the rotors along the deck, so they can be moved out of the way of cranes at port.
On the ship’s main control panel, a small, mint green console the size and shape of a pulpit controls the speed and movement of the rotors in the open ocean.
There is a monitor displaying data such as wind direction and a key for a manual override.
Most of the time, the crew leaves it on automatic.

The rotor sails, unrecognizable to most people in the shipping trade, garner quite a bit of attention.
Mandas said that people on other ships radio the Afros after seeing them from afar, asking what, exactly, those things are.
He tells them they help save fuel, add speed and reduce environmental damage.
Longshoremen at the ports inquire about how they work; some wonder if they’re wind turbines or some kind of cargo that the ship will be discharging.
Off the coast of Vancouver, members of the Canadian Coast Guard, fascinated by the sails, asked the officers to turn them on so they could see them spin.

The attention isn’t always positive, however.
Mandas told me that, at a port in China, he was confronted by one of the stevedores.
Stevedores board ships to operate the cranes mounted on deck, and the rotor sails seemed to be partially blocking this stevedore’s line of sight.
He couldn’t understand what the man was saying, but screaming and gesticulation is something of a universal language: Mandas gathered that the man was annoyed.

The MV Afros has four cylindrical rotor sails, like this one, that harness wind power.
Credit...Spencer Lowell for The New York Times

Flettner rotors like the ones on the MV Afros are among the first in the water and can be installed in a matter of hours, but their reduction in fuel consumption is limited; they save an average of 3 percent to 15 percent on fuel.
Other sails in the works are projected to save as much as 30 percent in fuel use, on average.
They will be bigger and more powerful, with more sophisticated automation, maybe even augmented-reality cameras to compensate for sails blocking the view of the horizon.

Some of the ships under development use soft, square sails stacked onto masts, like the famously fast clipper ships of the 19th century, but with sleeker, larger designs.
Others look nothing like the ships of old.
One design calls for a narrow-bodied ship rising high above the water, so that part of the hull itself functions as a sail.
Another has a line of smooth, hard, upward-reaching sails along its center, arranged like the plates of a stegosaurus.
A fourth features rigid rectangular sails that would retract to allow ship-to-shore cranes to pull containers off at port.
There are even plans to fit cargo ships with huge kites that unfurl ahead of them, pulling the ship along on a good wind.

Over the past several years, some important players in the shipping industry have begun to invest in decarbonization, including wind propulsion.
A.P. Moller-Maersk, one of the largest vessel operators in the world, has studied technologies that could help, as has Cargill, the food-and-agriculture company, which is a major charterer of ships.
“We really see this as a massive change coming at us, and we better be part of that,” Jan Dieleman, the head of ocean transportation for Cargill, said.
Cargill looked at the wind-propulsion technologies available, including kites and rotor sails, and made a notably bold move: It chose to work with BAR Technologies, a start-up in Portsmouth, England, committing to pay for the company’s first sails — and the cost of installing them on one of the ships that Cargill charters — with the help of a grant from the European Union.
Beyond that, Cargill aims to charter at least 20 new wind-assisted ships over the next couple of years.

Portsmouth, which sits at the mouth of a natural harbor on England’s southern coast, was built on sail: Many centuries ago, at a time when international trade felt like the rarest of miracles, a French merchant with a fleet of sailing ships developed the port.
In 1194, Portsmouth was formally chartered as a market town.
But its sailing ships lost their dominance a long time ago, as newer vessels became increasingly large and bulky — powered first by coal, then by oil.
The modern ships outgrew the harbor and moved to wider and deeper ports on the outskirts of town.
What was once the thriving commercial and naval center was renamed Old Portsmouth.
Rather than being filled with warships and schooners, the piers of Old Portsmouth are now crowded with ferries and leisure yachts, their white masts tilting with the sway of the water.

In 2014, Ben Ainslie, a knighted Olympic sailor, mounted a campaign costing more than $100 million to win the America’s Cup sailing regatta from a headquarters in Old Portsmouth, building a modern glass-and-concrete structure, six stories high, to house 150 employees, including engineers, sailors and boat builders.
While sails had disappeared from commercial shipping, the America’s Cup had become the most technologically advanced regatta in the world — an engineering contest as much as a racing one — and a showcase for innovation in wind propulsion.
Ainslie’s building came to dominate the skyline of Old Portsmouth.

Early on, Simon Schofield, the naval architect who led the engineering team, and Martin Whitmarsh, the chief executive for Ben Ainslie Racing, had a wild notion: What if they could funnel the technological innovations from the America’s Cup campaign into bringing wind propulsion back to cargo vessels? They knew other companies were trying it and thought, with their engineering background, they could do it better.

Schofield set up shop in a small room next to the Ben Ainslie Racing cafeteria, gathered a few of the engineers from the racing team and began designing, under the name BAR Technologies.
The rigid sails they came up with, named WindWings, look like vertically mounted airplane wings, rising 120 feet or more, and consist of a steel frame wrapped in lightweight composite fibers hardened in resin.
They’re meant to be installed on a ship in groups of three to five, rotating and changing shape to catch the wind so that the vessel can harness more free power from any given gust.

Schofield grew up on Mersea Island on England’s eastern coast, the son of a boatbuilder.
His father made him his first sailboat — a single-masted green wooden dinghy named Polo — when he was 6.
Schofield can’t remember a time before he was sailing Mersea’s creeks and estuaries, throwing barbecues with his friends on marshy banks; leaping into one another’s boats; slapping his homework shut on a Wednesday night to race, with as many as a hundred other kids in dinghies, during Mersea’s weekly regattas.
It was on his boat that he learned to read the wind in the ripples on the water and catch a breeze as it slid along the curve of a cloud.
He found sailing to be like a game of chess: You have to see far enough into the horizon to plot your route across the water from one gust of wind to the next.

Today’s seafarers no longer know their way around wind; conventional combustion-engine ships mostly take the shortest straight-line route to their destination.
Part of an effective wind-propulsion system is software that can guide the ship onto routes that might not be the shortest — but, because of how the wind is moving, could be more fuel-efficient.
During a windy stretch, a cargo vessel could turn off its engines and be propelled entirely by the wind.
Modern wind propulsion, then, depends on teaching software, not seafarers, to gauge the best route.

By the time I visited Old Portsmouth, the Ben Ainslie Racing team had moved out of its building, largely leaving it to Schofield, now the company’s chief technology officer, and his workers.
BAR Technologies commandeered the top floor, an oval open-plan room with near-360-degree views overlooking the harbor and the historic rowhouses.
Schofield’s team had grown to 25, with a new hire coming in nearly every week.
Mechanical and systems engineers, computational-fluid-dynamics analysts and software developers worked in a quiet hush in front of wide monitors.

Bright yellow masking tape was arranged in loops on the floor — the central section 33 feet wide, with two sections 16 feet wide on either side — running nearly half the length of the office.
These were outlines, at full scale, of BAR Technologies’ WindWings.
The sails are designed to be fitted onto tankers and dry-bulk carriers, which transport unpackaged goods such as grain or coal.
Schofield looked up the building’s measurements and worked out that the office floor was 100 feet high, meaning the WindWings would be 24 feet higher.
I looked up, trying to imagine a sail rising to that height.

When Schofield first took on the task of making a sail fit for cargo vessels, he thought it would be easy: sort of like a yacht sail, but bigger.
But sails for a cargo ship need to be optimized for factors beyond just speed.
There were ports to consider, seafarers, shipowners, manufacturers, regulations, the placement of hatches, bird collisions, the not-uncommon prospect of a 36-foot wave breaking across the deck in the middle of a storm.

The design they ended up with, the WindWing, can be installed as a retrofit on existing cargo vessels or fitted onto newly built ships.
The sail is designed to pivot automatically, using sensors to gauge the speed and direction of the wind, to catch it and to make sure the ship keeps moving forward.
During a storm, or when the wind is blowing too strongly, the sails would automatically turn off, whipping in the wind without harnessing it.
To allow the ship to go under a bridge, or while it is at port, the wings would fold into themselves, then lower, flat, onto the surface of the deck — a 15-minute process — so they would be clear of the cargo hatches, cranes and railings of the ship.

While few ultramodern wind ships exist yet in physical form, eye-catching renderings are legion, depicting futuristic hulls that could never fit into any existing port or spindly sails mounted onto the top of a cruise ship that look more like antennae than something that can propel a vessel.
Schofield resisted the temptation to put out a rendering of the WindWing before completing the mathematical models needed to back up the sail’s performance.
He says many cargo-sail renderings risk not being able to stand up to technical scrutiny: “Very quickly it becomes no more than a cartoon.”

Schofield’s hope is to overdeliver later — thus maintaining the credibility of the design, the company and the whole idea of wind propulsion.
“The shipping industry is conservative,” he said.
“Lose their trust, and it will be harder to convince them the next time.” By the time the company’s designs hit the water, Schofield’s engineers expect average fuel savings of 30 percent.

Cargill and the E.U. will fund the first WindWings system to be retrofitted onto an enormous 750-foot dry-bulk carrier currently traveling the world.
The sails will be assembled at a shipyard in China and mounted onto the ship by the summer of 2022.

The price for the first prototype set is more expensive than John Cooper, BAR Technologies’ chief executive, would like.
He wouldn’t disclose the price, saying only that he believes the cost will fall by the time the sails are in mass production and that shipowners will see a full return on investment in just over five years.
(By the company’s calculations, a 210-deadweight-ton dry-bulk vessel retrofitted with three 164-foot sails could save around $1.5 million in fuel costs a year.
A larger ore carrier, with five sails, could save about $2.5 million.) Cooper’s ability to pull this off could determine whether BAR Technologies will, in coming years, be making just a handful of sails or thousands.


The MV Afros on the Mississippi River.
The shipping industry has thus far mostly resisted a transition to sustainable power.
Credit...Spencer Lowell for The New York Times

There’s a version of the future in which wind propulsion never takes off.
The shipping industry is fragmented and vast, with even Cargill chartering less than 2 percent of the more than 50,000 cargo vessels on the water.
Most companies are small and medium-size enterprises — run by shipping owners whose fleets number in the single or double digits, not the hundreds or thousands, and who are less willing to invest in expensive new technologies.

And for every BAR Technologies, there are numerous other modern sail companies that have developed preliminary designs and renderings but haven’t been able to find investors or customers who will pay to get the sails made.
Many have languished after the first tranche of money — usually the inventor’s own — has been spent and a third party hasn’t stepped in with more funding.

The International Maritime Organization, the United Nations body tasked with regulating international shipping, has also moved slowly when it comes to decarbonization.
According to a New York Times investigation published in June, shipping-industry representatives have wielded undue power at the I.M.O.
to advance interests counter to the organization’s stated goal to cut emissions, with influential countries including China, Brazil, Japan and India forcing watered-down regulations that would do little to reduce emissions.
Three years ago, under pressure from the European Union, as well as environmental advocacy groups and tiny Pacific Island nations vulnerable to climate change, the I.M.O. announced numerical targets to cut shipping’s emissions, but they were widely criticized as cosmetic.

One target, for example, is to cut greenhouse-gas emissions so that by 2050, all ships worldwide cumulatively produce half the amount they did in 2008.
But this target is not linked to regulations or enforcement mechanisms and doesn’t align with the global Paris Agreement to achieve carbon neutrality and keep the warming of the planet under 2 degrees by 2050.
Faïg Abbasov, a director at the Brussels-based environmental advocacy organization Transport and Environment, said that the shipping industry would need to fully decarbonize by 2050 for the atmosphere to stay below 2 degrees of warming.
But the I.M.O. itself projects that, despite the target of halving emissions by 2050, shipping emissions will, at best, fall 10 percent from the 2008 level at that point, or even increase by as much as 30 percent.

Natasha Brown, a spokeswoman for the I.M.O., said the organization acknowledges that more measures are needed and might consider additional ones between 2023 and 2030.
It is not clear whether any new regulations will be stringent enough to require shipowners to produce significantly less carbon, thus forcing them to invest in fuel-saving technology like sails.

Higher fuel prices would encourage the use of technologies like wind propulsion as companies look for ways to save on fuel.
One way to raise fuel prices would be with a carbon tax.
The Marshall Islands has proposed a tax of $100 per ton of carbon dioxide emitted, and Maersk, the shipping company, has called for an even higher tax, at $150 per ton, suggesting the momentum for a carbon tax is growing.
What’s not certain is whether any eventual tax will be big enough to change the way shipping operates — a counterproposal supported by the International Chamber of Shipping, an industry trade group, along with other countries, suggests a levy equivalent to just 67 cents per ton of carbon.
And if fuel costs don’t rise significantly, companies may not see a compelling reason to spend on wind propulsion.

But already, influential governments are working outside the I.M.O. to encourage change.
The European Union is planning to include shipping in a continental emissions-trading system, which would affect thousands of ships that sail into European ports.
In April, John Kerry, the presidential climate envoy for the United States, said the federal government plans to push the I.M.O. beyond its current decarbonization targets.

If, in this context, inventors can build a successful economic case for wind propulsion — a scenario that depends on a lot going right for them — more companies could soon place orders.
According to a 2016 study for the European Commission that analyzed cargo vessels’ routes, the savings from wind propulsion could, by 2030, make it economically viable for 3,700 to 10,700 existing ships.
And as older vessels are scrapped, new ships optimized to make the most of wind — with even better returns — would be rolling off shipbuilding yards.

Around that time, according to the Maersk Mc-Kinney Moeller Center for Zero Carbon Shipping, ships running on zero-carbon fuels should be hitting the market in significant numbers.
The price of some of these fuels is expected to be three to five times as expensive as the bunker fuel that ships usually use, which would make wind propulsion — which by then may save an average of 50 percent or more on fuel costs — even more attractive.
In 30 years, the shipping industry, with a complex energy mix including wind propulsion, would be positioned to fully decarbonize, as the last of the conventional combustion-engine ships reach the end of their lifetimes and are put to scrap.

At a harbor near Portsmouth, Schofield and I braced ourselves against gales of wind and intermittent flurries of rain.
We stood underneath a pair of racing boats he had designed, raised onto a dry dock, as he explained that the curves of the hulls were determined by the proprietary software his engineering team wrote for the America’s Cup, each optimized for the conditions the boats were expected to be in.
He says that, as exciting as the WindWing retrofits are, what he’s waiting for is the chance to build entirely new ships from hull to sail, using artificial intelligence to determine the shape of a hull and sails that would squeeze even more power from the wind, while making use of the zero-carbon fuels expected to emerge.
For all of Schofield’s fascination with the sails of the future, even he couldn’t imagine what these ships might look like.

Aurora Almendral is an American journalist based in Southeast Asia.
Her work has been recognized with an award from the Overseas Press Club of America, among other honors.
Spencer Lowell is a photographer in Los Angeles known for his images of scientific laboratories and industrial facilities and his portraits of leading researchers and corporate moguls.

Wednesday, July 7, 2021

Sentinel-6 Michael Freilich ocean-observing satellite starts providing science data


This map shows sea level measured by the Sentinel-6 Michael Freilich satellite from June 5-15. Red areas are regions where sea level is higher than normal, and blue areas indicate areas where it's lower than normal.
Credit: NASA Earth Observatory

From Meteorological Tech. Int by Helen Norman

Sentinel-6 Michael Freilich, a US-European collaboration to measure sea surface height and other key ocean features, such as ocean surface windspeed and wave height, released its first science measurements to users on June 22.

After six months of check-out and calibration in orbit, the Sentinel-6 Michael Freilich satellite, which launched from Vandenberg Air Force Base in California on November 21, 2020, has made two sea surface height data streams available to the public.


One of the sea surface height data streams is accurate to 2.3in (5.8cm) and will be available within hours of when the instruments on board Sentinel-6 Michael Freilich collect it.
A second stream of data, accurate to 1.4in (3.5cm), will be released two days after collection.

According to NASA, the difference in when the products become available balances accuracy with delivery timeliness for tasks like forecasting the weather and helping to monitor the formation of hurricanes.
More data sets, which will be accurate to about 1.2in (2.9cm), are slated for distribution later this year and are intended for research activities and climate science including tracking global mean sea level rise.

The satellite collects measurements for about 90% of the world’s oceans.
It is one of two satellites that compose the Copernicus Sentinel-6/Jason-CS (Continuity of Service) mission.


The joint U.S.-European Sentinel-6 Michael Freilich is the next in a line of Earth-observing satellites that will collect the most accurate data yet on sea level and how it changes over time.
With millimeter-scale precision, data from this mission will allow scientists to precisely measure sea surface height and gauge how quickly our oceans are rising.
The Sentinel-6 Michael Freilich satellite is part of the Sentinel-6/Jason-CS mission, a collaboration among NASA, ESA, EUMETSAT, and NOAA

The second satellite, Sentinel-6B, is slated for launch in 2025.
Together, they are the latest in a series of spacecraft starting with TOPEX/Poseidon in 1992 and continuing with the Jason series of satellites that have been gathering precise ocean height measurements for nearly 30 years.

Shortly after launch, Sentinel-6 Michael Freilich moved into position, trailing the current reference sea level satellite Jason-3 by 30 seconds.
Scientists and engineers then spent time cross-calibrating the data collected by both satellites to ensure the continuity of measurements between the two.
Once they are assured of the data quality, Sentinel-6 Michael Freilich will then become the primary sea level satellite.

“It’s a relief knowing that the satellite is working and that the data looks good,” said Josh Willis, project scientist at NASA’s Jet Propulsion Laboratory (JPL) in Southern California.
“Several months from now, Sentinel-6 Michael Freilich will take over for its predecessor, Jason-3, and this data release is the first step in that process.”

Sentinel-6/Jason-CS is being jointly developed by the European Space Agency (ESA), EUMETSAT, NASA and NOAA, with funding support from the European Commission and technical support from France’s National Centre for Space Studies.
JPL is contributing three science instruments for each Sentinel-6 satellite: the Advanced Microwave Radiometer, the Global Navigation Satellite System – Radio Occultation, and the Laser Retroreflector Array

Links :

Tuesday, July 6, 2021

France & misc. (SHOM) layer update in the GeoGarage platform


271 nautical raster charts updated

With map 7639 (Approaches and harbor of St. Peter's Island) the Shom reaches the podium (3rd) for the map exhibition competition of the 29th International Cartographic Conference of the ICA (International Cartographic Association) in Tokyo

Deep-sea mining could start in two years after Pacific nation of Nauru gives UN ultimatum

Deep sea mining off the Papua New Guinea coast. Photograph: Nautilus minerals

From The Guardian by Kate Lyons

The International Seabed Authority has two years to finalise regulations governing the controversial industry

Deep-sea mining has been given the go-ahead to commence in two years, after the tiny Pacific island nation of Nauru notified the UN body governing the nascent industry of plans to start mining.

Triggering the so-called “two-year rule”, which some have called the nuclear option, the International Seabed Authority (ISA) now has two years to finalise regulations governing the controversial industry.

If it is unable to do so, the ISA is required to allow mining contractors to begin work under whatever regulations are in place at the time.

Nauru’s president, Lionel Aingimea, notified the ISA of the intention of Nauru Ocean Resources Inc (NORI), a subsidiary of a Canadian company called DeepGreen, to apply for approval to begin mining in two years in the Clarion-Clipperton Zone (CCZ) in the North Pacific Ocean between Hawaii and Mexico.

Aingimea’s letter, dated 25 June, asked the ISA “to complete the adoption of rules, regulations, and procedures required to facilitate the approval of plans of work for exploitation in the area within two years” from 30 June.

Nauru believed draft deep-sea mining regulations were nearly complete after seven years of talks, Aingimea’s letter said.

A rare deep-sea cirrate octopod. Sir David Attenborough has backed calls for a halt to deep sea mining, which conservationists warn could have huge impacts on wildlife and climate change. Photograph: NOAA Office of Ocean Exploration and Research/PA


Environmental groups, the EU Parliament, several Pacific nations including Fiji and Papua New Guinea, and Sir David Attenborough, have called for a moratorium on deep-sea mining, arguing that too little is known about its impact.

Last week, more than 350 scientists from 44 countries signed a petition calling for a moratorium on deep-sea mining “until sufficient and robust scientific information has been obtained”.

Jessica Desmond, Oceans campaigner for Greenpeace Aotearoa, said: “We are currently in the middle of a climate and biodiversity crisis, we know that deep sea ecosystems are some of the most important ecosystems on the planet and we are seeing this relentless and reckless push to mine these areas, despite the fact that scientists are very clearly warning us that the outcomes could be disastrous.”

“It’s very disappointing, it’s very foolhardy… and very dangerous,” said Duncan Currie, an international lawyer who has worked in oceans law for 30 years.

He represents the Deep Sea Conservation Coalition which is calling for a moratorium on deep sea mining.

Currie said the two-year rule was designed to be used if a country was ready to mine and then found their path to do so blocked by a few countries in the ISA, or if progress toward adopting regulations to govern deep-sea mining had stalled, but that neither situation was the case.

“A very important consultation is happening next week,” said Currie, in reference to a 3 July deadline for responses to draft standards and guidelines.

“They can hardly complain that things aren’t happening when they’re happening next week.

“If we’re in a situation where a company has tested all their equipment and they’re frustrated by the regulatory environment, we might expect to see this, but we haven’t seen that.”

DeepGreen is looking to extract polymetallic nodules from the seabed.

The nodules, which resemble potatoes and are thought to take millions of years to form, are rich in manganese, nickel, cobalt and rare earth metals, key components of batteries for electric vehicles. DeepGreen argues deep-sea mining is a less environmentally and socially damaging alternative to terrestrial mining, and is crucial for transitioning to a greener economy.

Rocks called ‘polymetallic nodules’ are seen on the seabed in the Clarion Clipperton Zone of the Pacific Ocean.
Photograph: GSR/Reuters

DeepGreen is in the process of merging with blank-cheque company Sustainable Opportunities Acquisition Corp (SOAC) to become The Metals Company. The Metals Company plans to list on the Nasdaq in the third quarter.

But SOAC said in a filing to the US Securities and Exchange Commission (SEC) last week it was not yet known whether mining the seabed would have less impact on biodiversity than mining for the same quantity of metals on land.

“We cannot predict ... whether the environment and biodiversity is impacted by our activities, and if so, how long the environment and biodiversity will take to recover,” it said.

DeepGreen has deals with Nauru, Tonga and Kiribati for CCZ exploration rights covering 224,533 square km, roughly the area of Romania.

DeepGreen did not respond to requests for comment for this story. In response to questions about invoking the two-year rule for a previous story, a spokesperson told the Guardian last week that the two-year rule was “only available to sponsoring states to use, not contractors like DG, which cannot invoke it” but that it was a “a valid option available to all member states of the International Seabed Authority”.

The Nauru government did not respond to requests for comment.

Links :

Monday, July 5, 2021

Climate change: Extremes committee validates Antarctic record heat

Image copyright NOAA
Esperanza station also held the previous record high temperature of +17.5C which occurred in 2015

From BBC by Jonathan Amos

A new record high temperature for the Antarctic continent of +18.3C has been confirmed by the World Meteorological Organization (WMO).


It occurred on 6 February last year at Argentina's Esperanza research station.

The mark was widely reported at the time but has now been validated by a WMO committee set up to check extreme weather data from around the globe.

The same group rejected an even higher Antarctic claim for 2020 of +20.75C, "recorded" on Seymour Island.

This again received international headlines, but the committee found the sensor set-up incorporated into a Brazilian permafrost experiment had not been properly protected from direct sunlight.




Thermometers are supposed to record air temperatures inside a ventilated covering, or screen.

The WMO team said that on Seymour Island this took the form of a modified length of scaffolding pipe and would likely therefore have introduced a warming bias into any data readings.

Nonetheless, temperatures on the normally frigid Antarctic continent have been rising, especially along its peninsula - the great tongue of terrain that stretches north in the direction of South America.

Over the last 50 years, the peninsula warmed almost three degrees.

And although no official temperature recording has yet gone above +20C on the continent and its close-by islands, it's just a matter of time, says Prof John King from the British Antarctic Survey (BAS).

"If you consider all the area covered by the Antarctic Treaty - that's all land south of 60 degrees South latitude - then we had a temperature of +19.8C in January 1982 on Signy Island.

"Okay, that's from the maritime Antarctic rather than the continent proper, but I wouldn't rule out seeing +20C temperatures somewhere in the northeast Antarctic Peninsula sometime within the next decade," the WMO extremes committee member told BBC News.




One of the drivers of the rise in temperatures is the strengthened westerlies that now blow around the continent.

This powerful airflow produces warming conditions on the eastern, leeward side of the peninsula's mountainous spine.

Such warm, downslope winds are well known across the Earth, and wherever they occur they tend to have a local name.

The Chinook winds that drop over the Rockies and Cascades in North America are an example of this phenomenon.
In the Antarctic, they are known as Foehn winds - a title originally used in Alpine Europe.

The incidence of these warmer conditions has been increasing on the Antarctic Peninsula.
The Foehn winds appear also to be moving poleward as well.
"The occurrence of Foehn winds varies greatly from year to year," explained Prof King.
"During the latter part of the last century, there was a strengthening and somewhat southward movement of the circumpolar westerly winds, which meant that this was probably contributing towards more intense Foehn on the eastern side of the peninsula and hence the rather rapid warming trend we saw there.
"That strengthening trend in the westerlies eased off a bit towards the end of the 20th Century and into the first part of the 21st Century, which meant the temperature trend also eased off a bit. But I think there are now indications that this phenomenon is picking up again, and is likely to be an important contributor to future warming in the region."

Image copyright BAS
The Foehn winds drop down the eastern side of the peninsula mountains

The Antarctic continent spans an area of 14 million sq km (roughly twice the size of Australia), and is covered by 26.5 million cubic km of ice.

Its weather stations are sparse but average annual temperature are seen to range from about −10C at the coast to -60C in the highest parts of the interior.

Satellites can measure the "skin temperature", or the temperature "to the touch", of the continent and have taken readings below even -90C in places.
But meteorologists are concerned with standard air temperatures and these are measured about 1.5m off the surface.

Using this definition, the coldest temperature ever recorded in the Antarctic stands at -89.2C. This occurred at the Russian Vostok station on 21 July 1983.

Links :

Sunday, July 4, 2021

Ocean drifters

Ocean Drifters from Plymouth University
Drawing upon Richard Kirby's plankton imagery, Ocean Drifters reveals how the plankton have shaped life on Earth and continue to influence our lives in ways that most of us never imagine.
Further information about the plankton can be found at the Ocean Drifters website (oceandrifters.org) and in the popular book about plankton also titled "Ocean Drifters, a secret world beneath the waves".
